Armor-Clad Fencing
Aluminum Fence Specs
PICKETS:
5/8” x 5/8” 6063-T6 aluminum. Wall thickness .050”. Spacing is 3-13/16”.
STRINGERS:
1” x 1” x 72” long. Top thickness .055”. Side thickness .085”.
SCREWS:
All assembled panels include stainless steel screws with painted heads.
Aluminum Post & Gate Specs
POSTS:
2” x 2” line, corner, and end posts are .060” thick. Gate posts are .125” thick.
GATES:
TIG welded construction. Furnished with self-closing hinges.
MISC:
All posts include caps. All screws included with job kit orders.
KEEP IN MIND:
All fencing components are powder coated after punching and notching are completed
